200KG Automatic Industrial Steam Boiler , Gas Fired Steam Boiler Energy Saving

Name: 200KG Automatic Industrial Steam Boiler Gas Fired Steam Boiler Energy Saving
Brand: SWET
Price: 1 USD

Wholesale 200KG Automatic Industrial Steam Boiler , Gas Fired Steam Boiler Energy Saving from china suppliers

Brand Name : SWET

Model Number : LSS-6007

Certification : ISO9001

Place of Origin : HENAN,CHINA

MOQ : 1 SET

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000 SETS PER YEAR

Delivery Time : 10 WORKING DAY

Packaging Details : The New Type 200kg steam boiler bady with plywood packaging.

Product name : 200kg LPG steam boiler

Item : LSS-6007 LPG steam boiler

Design fuel : gas/oil

Color : Customer's Requirement

Warranty : 12 Months

Thermal efficiency : over 92%

The biggest fuel consumption(Nm3/h) : 15.7

Rated evaporation (kg/h) : 200

Rated steam temperature(℃) : 170

Rated steam pressure(Mpa) : 0.7

Size : 1600x1500x2300mm

Material : Boiler steel

Burner : Italy Riello

Weight : 1.2t

Contact Now

200KG Full Automatic Control LPG Gas Steam Boiler For Dyeing Industry

1. The steam boiler fuels are renewable biomass; the running cost is one fifth of electric boiler, one third of oil boiler.

2. The steam boiler full automatic control. Just connect the water and electricity; press the key, then the boiler will automatically enter the automatic running, safer and more convenient.

3. The steam boiler built-in steam separator solves the problem of steam with water to ensure the quality of the steam.

4. The steam boiler fuel is energy-saving and environmentally friendly biomass. It is renewable, wide range of sources, affordable, and its running cost is one sixth of electric boiler, and a third of oil-fired boiler. There is no smoke and dust put off when burning. Only a small amount of powdery ash residue after completely burned retained in the ash collection chamber, easy to handle.

Gas steam boiler technical parameters

Gas steam boiler technical parameter
Rated evaporati on	Rated pressure	Rated steam temperat ure	Feed water temperat ure	Design thermal efficienc y	Water capacit y	Steam outlet	water intake	Drain valve	Gas supply pressur e	Gas pipe diamet er	Dimensions			Shippin g weight	Full load biomass consuption
											L	W	H
Kg/h	Mpa	℃	℃	%	L	DN	DN	DN	Kpa	DN	mm	mm	mm	T	Nm³/h
80	0.7	170℃	20℃	90%	27	15	15	20	2-3.5	20	1050	1000	1500	0.6	6.5(NG)
100	0.7	170℃	20℃	90%	27	15	15	20	2-3.5	20	1150	1100	1600	0.5	8.4(NG)
150	0.7	170℃	20℃	90%	27.6	15	15	20	2-3.5	20	1250	1200	1700	0.7	11.7(NG)
200	0.7	170℃	20℃	90%	27.6	20	15	25	2-3.5	20	1600	1500	2300	1.2	15.7(NG)
300	0.7	170℃	20℃	92%	28	32	15	25	3.5-5	20	1700	1600	2300	1.3	22.3(NG)
400	0.7	170℃	20℃	92%	28.6	32	15	25	3.5-5	32	2350	1750	2200	2.8	30.5(NG)
500	0.7	170℃	20℃	92%	29	40	15	25	3.5-5	32	3200	1500	2100	3	37.9(NG)
600	0.7	170℃	20℃	92%	29	40	15	25	3.5-5	32	3200	1500	2500	4.2	46.9(NG)

200KG Automatic Industrial Steam Boiler , Gas Fired Steam Boiler Energy Saving
